DC or AC control 10 - 120 A three phase solid state relay with LED indicator

FOB Reference Price:Get Latest Price
US $1-30 / Piece | 1 Piece/Pieces three phase solid state relay (Min. Order)
Supply Ability:
10000 Piece/Pieces per Month three phase solid state relay
Port:
Shanghai / Ningbo
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
NQQK
Model Number:
NKTH4048ZD3
Theory:
Solid State Relay
Usage:
Protective
Size:
Miniature
Protect Feature:
Sealed
Contact Load:
High Power
Name:
three phase solid state relay
Certifications:
CE
Color:
Black
Electricity Type:
AC
Number of Pole:
3
Load Current:
40A
HS Code:
8536490000
Load voltage:
24-480VAC
Control voltage:
3-32VDC
Max Input current:
120A
Packaging & Delivery
Packaging Details
carton
Delivery Time
1-3days

DC or AC control 10 - 120 A three phase solid state relay with LED indicator



Product Description

Introduction:

Solid state relay (SSR) is an electronic switching device that switches states when an external voltage is applied along its n-type and p-type junctions. SSR has a small control signal that controls a larger load current or voltage. It consists of a sensor which responds to an appropriate input (control signal), a solid-state electronic switching device which switches power to the load circuitry, and some coupling mechanism to enable the control signal to activate this switch without mechanical parts. The relay may be designed to switch either AC or DC to the load. It serves the same function as an electromechanical relay, but has no moving parts.



Features:
Adjustable output voltage
Analog control signals: 4-20mA, 0-10V DC, variable resistor 220-560kOm
There isn’t contact bounce and sparks during switching
Removable finger proof cover available
Low power consumption
Panel mount



Models explanation:

NKDH.......40.........48........ZD3



    1            2           3           4

1.NK – Code
NKDH – single-phase solid state relay (10 – 120A)
NKDM – industrial class solid state relay (100 – 500A)
NKTH – three-phase solid state relay (10 – 120A)
NKTR – motor reversing solid state relay (10 – 40A)


2.40 – load current 40A (10 – 500A)


3.48 – load voltage 24-480V AC, 38 – 24-380V AC, 23 – 5-220V DC


4.ZD3 – control signal type(swithing mode)
VA – variable resistor 220-560 /2 (phase control)
LA– analog signal 4-20mA (phase control)
VD – analog signal 0-10V DC (phase control)
ZD – control voltage 10-30V DC (switching at zero crossing)
ZD3 – control voltage 3-32V DC (switching at zero crossing)
ZA2 – control voltagte 70-280V AC (switching at zero crossing)
DD3 – control voltage 3-32V DC (DC voltage switching)

 Technical specifications:







380VAC 0 ~ 10VDC 100% 120A Adjustable output voltage phase control SSR solid state relay 380VAC 0 ~ 10VDC 100% 120A Adjustable output voltage phase control SSR solid state relay 380VAC 0 ~ 10VDC 100% 120A Adjustable output voltage phase control SSR solid state relay 380VAC 0 ~ 10VDC 100% 120A Adjustable output voltage phase control SSR solid state relay 380VAC 0 ~ 10VDC 100% 120A Adjustable output voltage phase control SSR solid state relay







Trade Information
Trade TermsFOB ,CIF ,CFR,EXW,DDP
Payment termsT/T,L/C,Western union,Paypal,Escrow,MoneyGram
Payment conditions30% deposit in advance,70% balance before shipping.
Delivery time3-7working days after deposit,2-4 working days for inventory
PackingNeutral carton,Wooden case for large size
ShippingBy sea,by air and by express delivery
